RoboAccess_Pal S

Try out Sidel’s new online cobotic/robotic palletizing configurator!
By entering just 10 simple production details, you can obtain a fully adapted palletizing cell’s layout and its corresponding Return on Investment!

PRODUCT INFO:

Brand owners from the Food, Home, and Personal care market segments are often looking for compact affordable palletizing systems for their low/medium speed packaging lines.

Cobotic solutions have a strong presence within these segments. But some applications are reaching the limits of this technology in terms of speed and payload. Traditional robotic palletizers, despite they can offer higher technical performances, have larger footprint and longer Return on Investment.

With RoboAccess_Pal S, Sidel has made the union of the best from the cobotic and robotic worlds.

Combining Robotics and Cobotics: finding high palletizing performances in a compact footprint

Benefitting from 50+ years of expertise in palletizing with 5,000 installations worldwide including 1,100 in robotics and 140 in cobotics, this new compact solution provides a high level of agility, operability, and performances.

TOP 3 BENEFITS:

  • Less than 12m² footprint for 2 stations and less than 8m² for 1 pallet station
  • Speed up to 12 cycles/min
  • Payload up to 25kg

Angel Meza - Project manager at the Beiersdorf plant in Argentona (Spain):

"We were looking for an affordable palletizer that would fit into the narrow area we used for manual palletizing. Cobotic units without guarding do not meet our internal safety standards and we also wanted a futureproof solution that could handle payload and speed increases in the event of line upgrades. That's why we chose Sidel's combination of robotics and cobotics."

"Sidel’s RoboAccess_Pal S robotic palletizer was perfect for us as it has a great performance/footprint ratio as well as being equipped with guards that can be folded if it needs to be moved to another line. Five months after its installation, our team is very happy with the solution as it is simple and user-friendly. That’s why we are studying the acquisition of further units!"

CONTACT

Online configurator

Cobot/Robot

Download

RoboAccess_Pal S

Features

Speechless combination of performances

  • Speed up to 12 cycles/min (1 to 6 cases per payload depending on size)
  • Payload up to 25kg (25kg with vacuum gripper and 20kg with clamping gripper)
  • Less than 12m² footprint for 2 stations and less than 8m² for 1 pallet station
  • Return on Investment from 1 to 2 years in average* (* based on one operator - 2 shifts from Europe / N. America regions)
  • Delivery time of 10 weeks
  • Pallet height up to 1700 mm
  • All major pallet sizes
  • New patented clamping head design concept, with independent clamps, optimizing overall cell footprint
  • Patented mobile physical curtain system allowing the reduction of machine footprint compared to light curtains

Agility

  • Extensive secondary packaging capability thanks to large gripping head range including:
    • Foam plates
    • Suction cups
    • New patented clamping head made of carbon fibber and 3D printed parts, to lighten the tooling weight to consequently increase the case/pack payload
  • Modular industrialized configurable concept: large library of modules allowing various machine configurations
  • Fast and repeatable changeovers for vertical start-ups delivering ever-shorter production stops
  • Pallet pattern management thanks to PalDesigner® pallet configuration tool
  • Effortlessly movable capability in 15 minutes with easy to install Plug & Play features thanks to patented folding guarding system

Operability

  • Safe and ergonomic to operate: full pallet removal and new empty pallet supply done in hidden time with full protection thanks to patented mobile physical curtain system isolating the operator from robot working on 2nd pallet station
  • Clear & centralized operator guidance for fast problem solving, with lots of features embedded in the user-friendly HMI: Standard Operating Procedures (SOP), One Point Lesson (OPL), …
  • Digital, automation & regulation expertise: OMAC compliant (software totally designed to be Pack ML incl. Make2Pack) while being compatible with Sidel EVO-On digital service platform
  • 2 Automation standard from 2 major brands with worldwide set-up and availability
