Home / Equipment / Filling machines / Sidel Matrix Filler SF300 FM

Sidel Matrix Filler SF300 FM

With its magnetic flow meter, the Sidel Matrix Filler SF300 FM is able to fill both still and carbonated beverages with the utmost precision.

The Sidel Matrix Filler SF300 FM delivers high filling accuracy and quick changeovers without product loss and its beverage external tank is easy to clean, saving time.

  • Electronic filler with magnetic or mass flow meter volume control
  • High flexibility for optimal deflection, even when working wit different bottle shapes or beverage types
  • Flexibility allows for quick, easy beverage/bottle format changeover
  • Filler and mixer fully integrated through the compact, hygiene and safer Blendfill solution
CONTACT
Flexible filling output rate that matches your production needs
Bottles sizes   Max production output
(bottles per hour)		  Range
(number of valves)
 500 ml (CSD, 18°)  80,000 bph  32 - 216

Features

Top product quality

  • Integrated and separate electro-pneumatic components
  • No vertical movement of the bottles - avoids foaming
  • External beverage tank
  • Reduced filler environment under positive pressure (HEPA filters)
  • CIP automatic dummy cups

Consistency across multiple configurations

  • Upgradable platform to manage greater product flexibility
  • Carbonator or Mixer coupling with Blendfill configuration

Advanced robustness and reliability

  • Oversized and sturdy structure
  • Modules with proven reliability

Optimum uptime and highest productivity

  • Up to 98% efficiency
  • 30% less downtime for maintenance
  • Fully automatic changeover

Sustainable solution

  • Reduced filler enclosure available - smaller footprint with less chemical usage
  • Reduced electrical consumption using servomotors

Strict hygiene

Production of top quality beverages requires conditions of strict hygiene. Smaller filler enclosure improves food safety and reduces usage of chemical agents.

Filling environment covers only the space around the valves

  • Takes up 80% less space than traditional enclosures
  • Environment controlled by pressurised filtered air
  • Simple and clean design
  • Low consumption of chemical agents for external cleaning
  • Self-draining surfaces



Filler and mixer fully integrated - the compact, hygienic and safer Blendfill solution:

  • Sidel Matrix Mixer SM500 product tank used as filler tank
  • Simplified solution with fewer components and functions
  • Only one product tank
  • Only one pressure and level control
  • Shorter CIP/rinse time
  • Quick beverage changeover

Blendfill solution

Filler and mixer fully integrated - the compact, hygienic and safer Blendfill solution:

  • Sidel Matrix Mixer SM500 product tank used as filler tank
  • Simplified solution with fewer components and functions
  • Only one product tank
  • Only one pressure and level control
  • Shorter CIP/rinse time
  • Quick beverage changeover
