MACHINE FEATURES |
||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Max Mechanical Output (bph) | 5200 - 1 Lit. 1800 - 2 Lit. |
|||||||||
Machine Dimensions L x W x H (mtr) | 2.3x2.7x1.9 | |||||||||
Dimensions with Performa Feeder L x W x H (mtr) | 6.1x3.6x3.0 | |||||||||
Number of Heating Modules | 4 | |||||||||
Number of Heaters per Module | 8 x 1.5 kw | |||||||||
PC Industrial Processor | Intel E620T | |||||||||
PC Screen | Touch Screen | |||||||||
No. of cavities for 1 Liter bottle | 4 | |||||||||
No. of cavities for 2 Liter bottle | 2 |
BOTTLE SPECIFICATIONS |
||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Max. Bottle Diameter (mm) | 110 | |||||||||
Max. Bottle Volume (Liters) | 2 | |||||||||
Max. Bottle Height (mm) | 360 | |||||||||
Max. Perform neck Dimension (mm) | 38 | |||||||||
Max. Perform Height incl. neck (mm) | 160 |
PERFORMANCE OEE |
||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Mechanical Efficiency (mm) | 95% | |||||||||
Mold Changeover Time (in minutes for 2 technicians) | 45 |
ENERGY |
||||
AIR | Output (Lit. x bph) |
Low Pressure Air for System @ 8 bar (cfm) | Low Pressure Air @ 8 bar with Air Recovery (cfm) | High Pressure Air for Blowing @ 40 bar (cfm) |
0.25 x 5200 0.5 x 5200 1.0 x 5200 2.0 x 1800 |
81 81 81 34 |
44 20 0 0 |
106 141 196 128 |
|
INSTALLED ELECTRICAL POWER 415V AC 50Hz ± 5% |
48 kW (Estimated consumption) 55-60% |
|||
WATER (For Over Shields + Mold Cooling @8-12°C & 4 bar pressure) | 50 Lpm |
