Features Specs Perf. OEE Energy
MACHINE FEATURES |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Max Mechanical Output (bph) | 4400 | |||||||||
| Machine Dimensions L x W x H (mtr) | 2.4x2.3x1.6 | |||||||||
| Dimensions with Performa Feeder L x W x H (mtr) | 4.6x2.8x2.2 | |||||||||
| Number of Heating Modules | 3 | |||||||||
| Number of Heaters per Module | 7 x 1 kw | |||||||||
| PC Industrial Processor | Intel E620T | |||||||||
| PC Screen | Touch Screen | |||||||||
BOTTLE SPECIFICATIONS |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Max. Bottle Diameter (mm) | 62 | |||||||||
| Max. Bottle Volume (Liters) | 0.33 | |||||||||
| Max. Bottle Height (mm) | 175 | |||||||||
| Max. Perform neck Dimension (mm) | 30 | |||||||||
| Max. Perform Height incl. neck (mm) | 110 | |||||||||
PERFORMANCE OEE |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Mechanical Efficiency (mm) | 95% | |||||||||
| Mold Changeover Time (in minutes for 2 technicians) | 45 | |||||||||
ENERGY |
||||
| AIR | Output (Lit. x bph) |
Low Pressure Air for System @ 8 bar (cfm) | Low Pressure Air @ 8 bar with Air Recovery (cfm) | High Pressure Air for Blowing @ 40 bar (cfm) |
| 0.1 x 4400 0.2 x 4400 0.33 x 4400 |
68 68 68 |
NA | 32 40 57 |
|
| INSTALLED ELECTRICAL POWER 415V AC 50Hz ± 5% |
27 kW (Estimated consumption) 55-60% |
|||
| WATER (For Over Shields + Mold Cooling @8-12°C & 4 bar pressure) | 30 Lpm | |||
